| Article number: |
M48/40 |
| Availability: |
More on the Way to us |
| Delivery time: |
More on the Way to Us |
- Used to adjust the working distance of larger cameras and similar accessories with M48 thread
- Telescope side M48 internal thread, 3.5 mm depth
- Eyepiece-/camera side M48 external thread, 3 mm depth
- 40 mm optical path length
- Also used as M48 / 2" nose piece with 36mm insertion depth, safety kerfs and 5 mm optical height
Modern cameras are usually characterised by extremely short optical heights, in order to be able to be mounted on various telescope constructions. The old T-2 standard with 5mm thread depth is a hindrance to this. To take care of this new development, all new Baader T-2 and M48 parts are delivered with the new 3 mm standard.
| MANUFACTURER |
Baader Planetarium |
| SKU (#) |
2958640 |
| EAN CODE |
4047825042866 |
| OPTICAL LENGTH (MM) |
40 (or 5) |
| CLAMPING SYSTEM |
no clamp |
| USAGE |
Adjusting the distances of accessories with M48 thread, M48 / 2" Nosepiece |
| INNER DIAMETER / CLEAR APERTURE (MM) |
45 mm |
| OUTER DIAMETER |
53 mm |
| INNER CONNECTION (LENS SIDED) |
Barrel, Thread, M48, 2" (50,8mm) |
| OUTER CONNECTION (EYEPIECE/-CAMERA-SIDED) |
Thread, M48 |
| COMPATIBLE BRANDS |
Baader Planetarium |
| TYPE OF ADAPTER |
Extension |
