Askar SQA130 Petzval Refractor Telescope
| Article number: | ASKAR-SQA130 |
| Availability: | More on the Way to us |
| Delivery time: | More on the Way to Us |
The Askar SQA130 is a large-aperture, fast Petzval astrograph designed for wide-field deep-sky astrophotography and high-resolution imaging. It features a 130mm aperture, 624mm focal length, and fast f/4.8 focal ratio, providing a combination of substantial light-gathering capability and a wide imaging field.
The SQA130 uses a five-element, fully air-spaced Petzval APO optical design incorporating two SD glass elements. The Petzval design provides integrated field flattening, eliminating the need for a separate field flattener and simplifying the imaging setup.
With a 55mm image circle, the SQA130 supports medium-format imaging while fully covering standard full-frame sensors with their 44mm image circle. Sharpstar specifies excellent star performance across the imaging field, with RMS star radius below 2 µm at the center and below 2.4 µm at the 55mm image-circle edge.
The SQA130 features a retractable dew shield that reduces the telescope's overall length for storage and transportation. The rear of the telescope includes M48, M54, and M68 adapters, providing flexible connection options for cameras and astrophotography accessories.
A 300mm Losmandy-style dovetail plate and multifunctional handle are included. The telescope is supplied in a protective carrying case.
FEATURES
• 130mm aperture
• 624mm focal length
• Fast f/4.8 focal ratio
• Five-element fully air-spaced Petzval APO optical design
• Two SD glass elements
• 55mm image circle
• Full-frame coverage at 44mm
• Supports medium-format imaging
• Built-in Petzval field flattening
• No separate field flattener required
• Excellent wide-field star performance
• Retractable dew shield
• M48, M54, and M68 rear adapters
• Adjustable rear connection distance from 46–76mm
• Recommended 55mm connection distance
• 300mm Losmandy-style dovetail plate
• Multifunctional handle
• Includes protective carrying case
OPTICAL SPECIFICATIONS
Aperture: 130mm
Focal Length: 624mm
Focal Ratio: f/4.8
Optical Design: Quintuplet Air-Spaced Petzval APO
SD Glass Elements: 2
Image Circle: 55mm
Full-Frame Coverage: 44mm
Medium-Format Coverage: 55mm
MECHANICAL SPECIFICATIONS
Length with Dew Shield Retracted: 650mm / 25.6"
Length with Dew Shield Extended: 764mm / 30.1"
Rear Adapters: M48 / M54 / M68
Rear Connection Distance: 46–76mm
Recommended Connection Distance: 55mm
Dovetail Plate: 300mm Losmandy-style
Dew Shield: Retractable
Weight
OTA Weight: 9.18 kg / 20.2 lb
Weight with Tube Ring and Dovetail Plate: 11.76 kg / 25.9 lb
INCLUDED ITEMS
• Askar SQA130 Optical Tube
• Multifunctional Handle
• 300mm Losmandy-style Dovetail Plate
• M48 Adapter
• M54 Adapter
• M68 Adapter
• Protective Carrying Case
• User Manual
